▋概述Description
T138拉断阀是应用于高压氢气加注,为了防止加氢软管受到非正常外力作用，导致软管或其他零部件受损而设计的安全防护产品。配套使用加氢枪T635型。
The T138 high-pressure hydrogen breakaway coupling is a safety protection product designed to prevent the hydrogen refueling hose or other parts from being damaged by abnormal external forces. Equipped with hydrogen refueling T635 type.
拉断阀与加氢软管连接，当拉断阀受到的轴向力达到预设值后，拉断阀的拉断轴会与拉断阀主体分离，两端自动密封，防止氢气外泄，保证加氢站的安全。
The breakaway coupling is connected with the hydrogen refueling hose. When the axial force received by the hose reaches the preset value of the breakaway coupling, the breakaway shaft of the breakaway coupling will be separated from the main body of the breakaway coupling. and the two ends will be automatically sealed to prevent hydrogen leakage and ensure the safety of the hydrogen refueling station.
T635加氢枪
T635系列加氢枪是针对车辆加注高压氢气而研发设计。
①加氢枪采用专利密封结构；
②IIC类防爆等级；
③采用高强度抗氢脆不锈钢。
